UW-03 Washing/Curing Machine

Description

⚙️ Technical Specifications

🧼 Washing System

• Magnetic impeller creates a strong vortex for deep cleaning
• Compatible with water or alcohol cleaning solutions
• Efficient removal of uncured resin from complex geometries

💡 UV Curing System

• UV wavelength: 405 nm
• LED configuration: 18 UV LEDs
• 360° curing with rotating platform for uniform exposure

📦 Build / Working Volume

• Washing container size: 210 × 160 × 200 mm
• Curing/drying volume: 215 × 165 × 300 mm

🖥️ Interface & Controls

• Touch controls
• LED display screen
• Simple user interface

📏 Physical Specifications

• Machine size: 325 × 303 × 436 mm
• Weight: 5.4 kg
